DEGSON DG300-7.5-02P-12-00AH-1 Screw Terminal 2-Pin Blue 2mm² 1pc

Image Representative of Range

DEGSON DG300-7.5-02P-12-00AH-1 Screw Terminal 2-Pin Blue 2mm² 1pc

Degson
Order Code:

02-4410

Brand: Degson MPN: DG300-7.5-02P-12-00AH-1 EAN-13: 2050003388856
Qty Unit Price (Ex VAT)
20+ £0.252
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Order in multiples of 1
383 in stock, despatched in 4 working days

The DEGSON DG300-7.5-02P-12-00AH-1 screw terminal features 2 pins and supports a 2 mm² wire connection, presented in blue. Designed for secure electrical connections, it protects wires and ensures reliability in printed circuit board applications. Ideal for use in electronics projects, terminal blocks, and other PCB interfaces.
Type Screw terminal
Actuation direction Perpendicular (to the PCB)
AWG (min.) 22
AWG max. 14
Colour Blue
Connector orientation Perpendicular (to the PCB)
Contact Material Brass tin plated
Cross section (flexible) (max.) 2mm²
Cross section (flexible) (min.) 0.32mm²
Cross section (inflexible) (max.) 2mm²
Cross section (inflexible) (min.) 0.32mm²
CS 7.5mm
Current Rating 10A
Enclosure material Polyamide 6.6
Factory colour Blue
Height 17.00mm
Length 9.10mm
Min. stripping length 5mm
Misc Attribute DG300-7.5-02P-12-00AH
No. of Levels 1
No. of Ways 2
Pins per row 2
Series DG350
Stripping length (max.) 6mm
Voltage Rating 300V
Width 15.00mm
Wire protection Yes
Wire Termination Screw, Wire Protector
