DEGSON DG127-5.0-02P-14-00AH-1 Screw Terminal 2 Pin 2.08 mm² Green

Image Representative of Range

DEGSON DG127-5.0-02P-14-00AH-1 Screw Terminal 2 Pin 2.08 mm² Green

Degson
Order Code:

02-4342

Brand: Degson MPN: DG127-5.0-02P-14-00AH-1 EAN-13: 2050002989849
Qty Unit Price (Ex VAT)
20+ £0.244
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Order in multiples of 1
788 in stock, despatched in 4 working days

The DEGSON DG127-5.0-02P-14-00AH-1 screw terminal is a green, 2-pin connector designed for secure electrical connections on printed circuit boards. It supports up to 2.08 mm² wiring and uses a lift system for reliable clamping. Common applications include PCB terminals and terminal blocks.
Pitch 5mm
No. of Ways 2
Mounting Type Through Hole
Mounting Direction Parallel (to the PCB)
Wire Gauge (AWG) 14
Wire Termination Rising Clamp
Actuation direction Perpendicular (to the PCB)
AWG (min.) 26
Colour Green
Contact Material Brass tin plated
Cross section (flexible) (max.) 2.08mm²
Cross section (flexible) (min.) 0.12mm²
Cross section (inflexible) (max.) 2.08mm²
Cross section (inflexible) (min.) 0.12mm²
CS 5mm
Current Rating 12A
Enclosure material Polyamide 6.6
Factory colour Green
Height 10.10mm
Length 8.10mm
Min. stripping length 6mm
Misc Attribute DG127-5.0-02P-14-00AH
No. of Levels 1
Pins per row 2
Series DG127
Stripping length (max.) 6mm
Type Screw terminal
Voltage Rating 300V
Width 10.00mm
Wire protection Yes
