DEGSON 15EDGVC-3.81-05P-14-00AH Socket Housing PCB 5 Pins 3.81mm Spacing

Image Representative of Range

DEGSON 15EDGVC-3.81-05P-14-00AH Socket Housing PCB 5 Pins 3.81mm Spacing

Degson
Order Code:

02-4242

Brand: Degson MPN: 15EDGVC-3.81-05P-14-00AH EAN-13: 2050003395526
Qty Unit Price (Ex VAT)
20+ £0.386
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Order in multiples of 1
1,173 in stock, despatched in 4 working days

The DEGSON socket housing PCB is a pluggable, multi-pin connector with a total of 5 pins and a contact spacing of 3.81 mm. This basic housing from DEGSON, model 15EDGVC-3.81-05P-14-00AH, is used in print applications with Combicon plug-in terminals. Typical applications include connecting or terminating wires on printed circuit boards in various electronic devices.
Board contact surface Tin plated
Case Material PA 66 UL94V-0
Compatible with (details) 15EDGK-3.81-05P-14-00AH
Connection Print
Connector contact surface Tin plated
Connector orientation Perpendicular (to the PCB)
Connector system board-to-board
Connector Type Socket, vertical vertical
Contact Material Brass
CS 3.81mm
Dim (L x W x H) 7.00 x 19.84 x 12.60 mm
Factory colour Green
Height 12.60mm
Length 7.00mm
Nominal Current 8A
Nominal current - rounded value 8A
Nominal Voltage 300V
Number of Rows 1
Pins per row 5
Total number of pins 5
Type Socket housing PCB
Width 19.84mm
