Chamberlain Door Security & Furniture Tubular motor 626578

Chamberlain Brand: Chamberlain
Chamberlain tubular motors are designed to drive shutters, offering varying specifications to accommodate different shutter sizes and weights.
Description Image Product Buy Pricing (Ex VAT) (Ø) Dimensions Height Length Max. current consumption Motor Power Power Consumption Rotational speed Suitable for shutter axle Ø Tensile force (max.) Torque Width Type Colour Hub Lead Length Operating Voltage
Chamberlain RPD10-05 Tubular Motor 40mm 10Nm for 5m² Shutters 20kg
Chamberlain RPD10-05 Tubular Motor 40mm 10Nm for 5m² Shutters 20kg
Extended range
Order code: 08-7686
MPN: RPD10-05

Available to back orderPlease contact us for lead time
1+ £56.89
Price per unit Ex VAT 		35mm (Ø x H) 35 mm x 35 mm 35mm 512mm 0.53A 121W 165W 17 U/min 40mm 20kg 10Nm 35mm Tubular motor Blue Not required 190cm 230V
Chamberlain RPD15-05 Tubular Motor 60mm 30kg 133W 15Nm 7.5m² Shutter Drive
Chamberlain RPD15-05 Tubular Motor 60mm 30kg 133W 15Nm 7.5m² Shutter Drive
Extended range
Order code: 08-7688
MPN: RPD15-05

7 available to back orderBack-order availability date - 27/12/2025
1+ £56.89
Price per unit Ex VAT 		45mm (Ø x H) 45 mm x 45 mm 45mm 512mm 0.60A 133W 178W 15 U/min 60mm 30kg 15Nm 45mm Tubular motor Blue Not required 190cm 230V
Chamberlain RPD25-05 Tubular Motor 25Nm 60mm 50kg Shutter Drive 191W
Chamberlain RPD25-05 Tubular Motor 25Nm 60mm 50kg Shutter Drive 191W
Extended range
Order code: 08-7690
MPN: RPD25-05

4 available to back orderBack-order availability date - 27/12/2025
1+ £75.45
Price per unit Ex VAT 		40mm (Ø x H) 40 mm x 45 mm 45mm 583mm 0.83A 191W 235W 15 U/min 60mm 50kg 25Nm 45mm Tubular motor Blue Not required 190cm 230V
