CamdenBoss CTB92VE/2S 2 Way 10A Vertical Free Plug Standard 3.81mm Pitch

CamdenBoss
Order Code:

21-2677

Brand: CamdenBoss MPN: CTB92VE/2S
Qty Unit Price (Ex VAT)
5+ £0.519
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Order in multiples of 5
135 in stock, despatched same dayContact us for additional stock

Vertical free plug female connector from the CamdenBoss CTB92VE Series, standard orientation, 2 poles, 3.81mm pitch.


  • Vertical body style
  • 10A current rating
  • 130/450V voltage rating
  • Rising clamp termination
  • Free hanging mounting
  • 1mm² wire size
  • Tinned phosphor bronze contact material
  • Polyamide 68 housing material, green colour
  • UL94V0 flame retardant
  • 1 mm² cable entry
  • Zinc plated steel captive M2 clamp screw
  • Guided pin alignment
  • Anti solder wicking terminal
  • CE approved
  • Manufacturer's part CTB92VE/2S

Rapid is an official distributor of CamdenBoss products. The products listed here are those that Rapid hold in stock – but we have access to many more, including the company's complete range of terminal blocks. Click here to make an enquiry about ordering CamdenBoss terminal blocks, connectors and enclosures.


Body Style Vertical Plug - Standard Orientation
Pitch 3.81mm
No of Ways Per Row 2
No. of Rows 1
Current Rating 10A
Colour Green
Wire Gauge (mm²) 1 mm2
Mounting Feature PCB
Mounting Type Pluggable rising clamp
Orientation Vertical
Series CTB
