Block PSR 230/24-1.3 Primary Switch Mode DIN Rail PSU 1 Phase 22-28.8 VDC 1.3A

Block
MPN
PSR 230/24-1,3
Brand
Block
EAN-13
4016138652178
Order Code
59-2820

Discontinued


Block PSR 230/24-1.3 is a Single Phase Primary Switched Mode Power Supply from the PSR 230 Range. The power supply is a voltage regulated unit, and ideal for use for applications in information technology (IT), automation, process and control technology.


  • Stabilised and adjustable output voltage
  • DC OK signalling via LEDs
  • Parallel connection option
  • Service friendly spring-loaded connector system
  • Panel installation on mounting rails
  • Input rated voltage 90 to 264V AC
  • Output rated voltage 22 to 28.8V DC
  • Output rated current 1.3A
  • No. of outputs: 1
  • Phases: 1
  • Connections: Spring cage terminals
  • Weight: 0.3kg
  • Dimensions: 40(W) x 90(H)mm
  • Type: Single Phase Primary Switched Mode Power Supply
  • Manufacturer's part: Block PSR 230/24-1.3
Output Voltage 22 - 28.8
Output Current 1.3
Number of Outputs 1
Dimensions 40(W) x 90(H)mm
Input Voltage 90 - 264 AC
