Block CUL 500/1,50 Enamelled Copper Wire 1.50mm ø 30m 0.50kg

Block
Order Code:

11-5017

Brand: Block MPN: CUL 500/1,50 EAN-13: 4016138670585
Qty Unit Price (Ex VAT)
1+ £21.90
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
19 available to back orderBack-order availability date - 15/01/2026

Block manufactures enameled copper wire with an outside diameter of 1.50 mm, available in 30 m coils weighing 0.50 kg. This enamel-coated wire, ideal for inductive coils and transformer windings, offers excellent insulation and heat resistance. The product is suitable for applications requiring thin, durable wire, such as in electric motors and transformers.
Number of Cores 1
Insulation Material Insulating base: min. Polyurethane, mod.
Length 30m
Type CUL 500
Cable Diameter 1.50mm
Current load capacity 6.5A
Max. temperature range (fixed installation) +155°C
Max. temperature range (flexible installation) +155°C
Packaged Yes
Sold by Metre No
Standards IEC 60317-20
Surface Polished
Temperature Range +155°C
