Block CUL 200/0,15 Enamel-Coated Copper Wire 0.15mm 1219m 0.20kg

Block
Standard range
Order Code:

11-5008

Brand: Block MPN: CUL 200/0,15 EAN-13: 4016138670356
Qty Unit Price (Ex VAT)
1+ £15.16
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
25 in stock, despatched in 4 working days

Block manufactures enamel-coated copper wire with an outside diameter of 0.15 mm, featuring an impressive length of 1219 meters while weighing 0.20 kg. This thin, insulated wire is ideal for use in transformer applications and crafting inductive coils due to its durability and conductive efficiency. The CUL 200/0.15 is especially suited for situations requiring precision coil winding and electrical insulation.
Insulation material Polyurethane
Cable features Enameled
Cable type CUL 200
Certification marks IEC 60317-20
Current load capacity 0.06A
Halogen-free No
Manufacturer part # CUL 200/0,15
Material (details) Insulating base: min. Polyurethane, mod.
Max. temperature range (fixed installation) +155°C
Max. temperature range (flexible installation) +155°C
Misc Attribute CUL 200/0,15
No. of leads 1
Outside diameter (w/o coating) 0.15mm
Packaged Yes
Sold per metre No
Surface Polished
Temperature range +155°C
Type Enamel-coated copper wire
Weight 0.20kg
