Block CUL 100/1,00 Copper Wire 1mm Dia 14m Enamel-Coated

Block
Standard range
Order Code:

11-5006

Brand: Block MPN: CUL 100/1,00 EAN-13: 4016138670318
Qty Unit Price (Ex VAT)
1+ £6.19
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
45 in stock, despatched in 4 working days

The Block Enamel-coated copper wire features an outside diameter of 1 mm, weighs 0.10 kg, and measures 14 m in length. Manufactured by Block, this enamelled wire is ideal for use in transformer coils and inductive circuits due to its insulation properties. Typical applications include use as a coil wire, thin wire, and insulated wire coils in various electrical components.
Insulation material Polyurethane
Cable features Enameled
Cable type CUL 100
Certification marks IEC 60317-20
Current load capacity 2.8A
Halogen-free No
Material (details) Insulating base: min. Polyurethane, mod.
Max. temperature range (fixed installation) +155°C
Max. temperature range (flexible installation) +155°C
No. of leads 1
Outside diameter (w/o coating) 1mm
Packaged Yes
Sold per metre No
Surface Polished
Temperature range +155°C
Type Enamel-coated copper wire
Weight 0.10kg
