Block CUL 100/0,28 Enamel-Coated Copper Wire 0.28mm 175m 0.10kg

Block
Standard range
Order Code:

11-4999

Brand: Block MPN: CUL 100/0,28 EAN-13: 4016138670424
Qty Unit Price (Ex VAT)
1+ £6.68
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
23 in stock, despatched in 4 working days

Block Enamel-coated copper wire, made by Block, has an outside diameter of 0.28 mm and weighs 0.10 kg for a length of 175 m. It is primarily used in applications like transformers and inductive coils due to its insulation and thin wire properties. This copper wire is ideal for creating compact and efficient electrical coils.
Insulation material Polyurethane
Cable features Enameled
Cable type CUL 100
Certification marks IEC 60317-20
Current load capacity 0.22A
Halogen-free No
Manufacturer part # CUL 100/0,28
Material (details) Insulating base: min. Polyurethane, mod.
Max. temperature range (fixed installation) +155°C
Max. temperature range (flexible installation) +155°C
Misc Attribute CUL 100/0,28
No. of leads 1
Outside diameter (w/o coating) 0.28mm
Packaged Yes
Sold per metre No
Surface Polished
Temperature range +155°C
Type Enamel-coated copper wire
Weight 0.10kg
