Block CUL 100/0,15 Enamel-Coated Copper Wire 0.15mm 609m 0.10kg

Block
Standard range
Order Code:

11-4997

Brand: Block MPN: CUL 100/0,15 EAN-13: 4016138670400
Qty Unit Price (Ex VAT)
1+ £9.16
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
37 in stock, despatched in 4 working days

Block manufactures enamel-coated copper wire with an outside diameter of 0.15 mm, weighing 0.10 kg and measuring 609 meters in length. This thin, coated wire is ideal for use in applications such as inductive coils and transformers. Its insulation makes it suitable for electrical applications requiring reliable performance.
Insulation material Polyurethane
Cable features Enameled
Cable type CUL 100
Certification marks IEC 60317-20
Current load capacity 0.06A
Halogen-free No
Manufacturer part # CUL 100/0,15
Material (details) Insulating base: min. Polyurethane, mod.
Max. temperature range (fixed installation) +155°C
Max. temperature range (flexible installation) +155°C
Misc Attribute CUL 100/0,15
No. of leads 1
Outside diameter (w/o coating) 0.15mm
Packaged Yes
Sold per metre No
Surface Polished
Temperature range +155°C
Type Enamel-coated copper wire
Weight 0.10kg
