Zettler Electronics AZ943-1AH-24DEGW PCB Relay 24V DC 15A 1 Piece

The Zettler Electronics AZ943-1AH-24DEGW is a PCB relay designed for 24 V DC applications, offering reliable switching capabilities with a compact form factor. Manufactured by Zettler Electronics, this mini relay is suitable for mounting on printed circuit boards and is ideal for use in consumer electronics, automotive systems, and industrial control equipment. Its robust construction ensures durability and long-lasting performance in various applications requiring precise control.

Coil Voltage	24V DC
Contact Configuration	1NO
Switching Current	15A
Coil Resistance	1600Ω
Contact Material	AgSnO2
Control Mode	monostable, 1 coil
Dimensions	(L x W x H) 19.00 x 15.30 x 15.70 mm
Durability	1 x 10E6
Height	15.70mm
Length	19.00mm
Max. pick-up Voltage	53.4V DC
Max. switching capacity	300W
Max. temperature	+70°C
Min. pick-up Voltage	18V DC
Minimum Temperature	-40°C
Mounting Type	PCB
Response Time	10ms
Switching Voltage Max	30V DC
Type	PCB relay
Width	15.30mm
