Zettler Electronics AZ943-1AH-12DE PCB Relay 12V DC 15A 1pc

Zettler Electronics
Order Code:

08-3689

Brand: Zettler Electronics MPN: AZ943-1AH-12DE EAN-13: 2050006598917
Qty Unit Price (Ex VAT)
5+ £0.815
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Order in multiples of 1
48 in stock, despatched in 4 working days

The Zettler Electronics AZ943-1AH-12DE is a PCB-mounted relay designed for 12 V DC applications. It is a mini relay suitable for printed circuit boards and offers reliable switching in compact spaces. Typical applications include automotive, industrial, and consumer electronics where space and reliability are critical.
Coil Voltage 12V DC
Contact Configuration 1NO
Switching Current 15A
Coil Resistance 400Ω
Contact Material AgSnO2
Control Mode monostable, 1 coil
Dimensions (L x W x H) 19.00 x 15.30 x 15.70 mm
Durability 1 x 10E6
Height 15.70mm
Length 19.00mm
Max. pick-up Voltage 26.8V DC
Max. switching capacity 300W
Max. temperature +70°C
Min. pick-up Voltage 9V DC
Minimum Temperature -40°C
Mounting Type PCB
Response Time 10ms
Switching Voltage Max 30V DC
Type PCB relay
Width 15.30mm
