Zettler Electronics AZ733-2CE-24DE PCB Relay 24V DC 12A 2 Change-Overs 1pc

Zettler Electronics
Order Code:

08-3598

Brand: Zettler Electronics MPN: AZ733-2CE-24DE EAN-13: 4064161192321
Qty Unit Price (Ex VAT)
1+ £3.99
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
331 in stock, despatched in 4 working days

The Zettler Electronics AZ733-2CE-24DE is a PCB relay designed for 24 V DC operation with a current rating of 12 A. It features two change-over contacts, making it suitable for switching applications. Typically used in printed circuit boards, it is ideal for automotive and industrial control systems.
Coil Voltage 24V DC
Contact Configuration 2CO (DPDT)
Switching Current 12A
Coil Resistance 1100Ω
Connection Solder pins
Contact Material AgSnO
Control Mode monostable, 1 coil
Dimensions (L x W x H) 29 x 13 x 25.9 mm
Height 25.9mm
Insulation Voltage 1000V
Length 29mm
Max. pick-up Voltage 45.7V DC
Max. temperature +85°C
Min. pick-up Voltage 16.8V DC
Minimum Temperature -40°C
Mounting Type PCB
Type PCB relay
Width 13mm
