Zettler Electronics AZ21501-1AET-24DF PCB Relay 24V DC 50A High-Power

Zettler Electronics
Standard range
Order Code:

08-3572

Brand: Zettler Electronics MPN: AZ21501-1AET-24DF
Qty Unit Price (Ex VAT)
1+ £2.47
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
18 in stock, despatched in 4 working days

Zettler Electronics manufactures the AZ21501-1AET-24DF PCB relay, featuring a 24 V DC rating and capable of handling 50 A. This mini relay is designed for printed circuit board mounting, making it suitable for compact electronic applications. It is commonly used in automotive and industrial control systems.
Type PCB relay
Coil nominal voltage 24V DC
Connection Solder pins
Contact material AgSnO2
Contact type 1 maker
Control mode monostable, 1 coil
Dim (L x W x H) 32.5 x 27.6 x 20.5 mm
Durability 1 x 10E7
Fall time 10ms
Height 20.5mm
Length 32.5mm
Max. switching capacity 1500W
Max. temperature +85°C
Min. temperature -55°C
Misc Attribute Zettler electronics
Resistance (coil) 384Ω
Response time 15ms
RoHS-compliant Yes
Switching current (max.) 50A
Width 27.6mm
