Weipu SP1311/P 5 II SP13 Bullet Connector 5-Pin Straight UV/Water Resistant

Image Representative of Range

Weipu SP1311/P 5 II SP13 Bullet Connector 5-Pin Straight UV/Water Resistant

Weipu
Standard range
Order Code:

13-5271

Brand: Weipu MPN: SP1311 / P 5 II EAN-13: 2050001514349
Qty Unit Price (Ex VAT)
2+ £3.82
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
Order in multiples of 1
37 in stock, despatched in 4 working days

The Weipu SP1311 / P 5 II is a straight bullet connector plug with 5 pins, part of the SP13 series. Manufactured by Weipu, it is suited for secure electrical connections in industrial and outdoor settings. This robust connector is commonly used in applications requiring reliable and waterproof connectivity.
Type Bullet connector
AWG 18
Cable Ø (max.) 8mm
Cable Ø range 5 - 8 mm
Cable Ø up to 5mm
Case material PPS
Connection Soldering
Connection angle 180°
Connector type Plug, straight
Contact material Gold plated
Cross-section range 0.785 mm² (max)
IP rating IP68
max. cross section 0.785mm²
Max. temperature +85°C
Min. temperature -25°C
Misc Attribute Weipu Connector
Nominal current 2A
Nominal current - rounded value 2A
Nominal voltage 150V
Number of pins 5
RoHS-compliant Yes
Seal Screw-type locking
Series SP13
Total no. of pins 5
