Weipu SP1310/P5I SP13 Plug Straight Bullet Connector 5 Pins UV Resistant

Image Representative of Range

Weipu SP1310/P5I SP13 Plug Straight Bullet Connector 5 Pins UV Resistant

Weipu
Standard range
Order Code:

13-5254

Brand: Weipu MPN: SP1310 / P 5 I EAN-13: 2050001514172
Qty Unit Price (Ex VAT)
2+ £3.29
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
Order in multiples of 1
104 in stock, despatched in 4 working days

Manufactured by Weipu, the SP1310 / P 5 I is a bullet connector plug, designed in a straight configuration with five pins. This connector, part of the SP13 series, is known for its durability and secure connections, suitable for various industrial and outdoor applications. It is often used in environments requiring reliable electrical connections, such as lighting systems and automotive electronics.
Type Bullet connector
AWG 18
Cable Ø (max.) 6.5mm
Cable Ø range 4 - 6.5 mm
Cable Ø up to 4mm
Case material PPS
Connection Soldering
Connection angle 180°
Connector type Plug, straight
Contact material Gold plated
Cross-section range 0.785 mm² (max)
IP rating IP68
max. cross section 0.785mm²
Max. temperature +85°C
Min. temperature -40°C
Misc Attribute Weipu Connector
Nominal current 32A
Nominal current - rounded value 32A
Nominal voltage 600V
Number of pins 5
RoHS-compliant Yes
Seal Screw-type locking
Series SP13
Total no. of pins 5
