Weipu SP1310/P 5 II SP13 Connector Plug 5 Pins UV Resistant Waterproof

Image Representative of Range

Weipu SP1310/P 5 II SP13 Connector Plug 5 Pins UV Resistant Waterproof

Weipu
Standard range
Order Code:

13-5255

Brand: Weipu MPN: SP1310 / P 5 II EAN-13: 2050001514189
Qty Unit Price (Ex VAT)
2+ £3.29
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
Order in multiples of 1
286 in stock, despatched in 4 working days

The Weipu SP1310/P 5 II Bullet Connector is a straight plug designed for reliable electrical connections, featuring five pins. Manufactured by Weipu, it is part of the SP13 series of round connectors, known for their durability. This connector is suited for industrial and outdoor applications where secure and stable connections are critical.
Type Bullet connector
AWG 18
Cable Ø (max.) 8mm
Cable Ø range 5 - 8 mm
Cable Ø up to 5mm
Case material PPS
Connection Soldering
Connection angle 180°
Connector type Plug, straight
Contact material Gold plated
Cross-section range 0.785 mm² (max)
IP rating IP68
max. cross section 0.785mm²
Max. temperature +85°C
Min. temperature -40°C
Misc Attribute Weipu Connector
Nominal current 32A
Nominal current - rounded value 32A
Nominal voltage 600V
Number of pins 5
RoHS-compliant Yes
Seal Screw-type locking
Series SP13
Total no. of pins 5
