Weidmüller 8950890000 TOP 230VAC / 48VDC 0.1A

A solid state relay with a 230V AC control voltage and a 5 to 48V DC 100mA load capacity. The SSR features a space-saving design and PUSH IN connection technology and is a compact alternative to electromechanical relays. Ideal for applications where electrical isolation and signal conditioning are required. Using solid sate switching will save space, reduce maintenance costs and increase reliability and system availability.

• Space-saving 6.1mm width
• Plug-in cross connections
• Enclosed design
• Long lifetime solid state technology
• LED Status indicator

Type	Relay
Mounting Type	Push-in
Height	79.5mm
Width	6.1mm
Length	44mm
Coil Current	1.75mA
Coil Voltage (DC)	48V DC
IP Rating	IP20
Maximum Temperature	+60°C
Min. temperature	-20°C
Operating Temperature	-20 to +60°C
Switching Voltage	48V DC
