Weidmüllers 8870110000 relay features a compact design suitable for applications requiring a 48V DC input and a single CO (changeover) contact configuration. Known for reliability, it is commonly used in switching operations within industrial automation systems. This miniature relay is ideal for space-constrained environments where efficient performance is crucial.
| Coil Voltage |
48V |
| Contact Configuration |
1CO (SPDT) |
| Alternative product |
CRI10048 |
| Ambient temperature |
-40 °C…70°C |
| Available until |
2024-10-31T00:00:00+01:00 |
| Certificate No. (CSA) |
249409-2426937 |
| Clearance and creepage distances for |
= 8mm |
| Coil Resistance |
5520 O ± 10 % |
| Colour |
Transparent |
| Contact Type |
1 CO contact (AgNi) |
| Continuous current |
16 A |
| control side - load side |
side |
| cycles, DC coil 10 x 106 |
V, 100 mA @ 5 V |
| DC operational voltage range |
Electrical service life 250 V AC resistive load |
| DC switching capacity (resistive), max. 384 W @ 24 V |
Switch-on delay |
| Delivery status |
Discontinued |
| Depth |
25.6mm |
| Depth (inches) |
1.0079 inch |
| Dielectric strength of open contact |
1 kVeff / 1 min |
| ECLASS 14 |
27-37-16-01 |
| ECLASS 15.0 |
27-37-16-01 |
| ETIM 10 |
EC001437 |
| ETIM 8.0 |
EC001437 |
| ETIM 9.0 |
EC001437 |
| GTIN (EAN) |
4032248613489 |
| Height |
29mm |
| Height (inches) |
1.1417 inch |
| Impulse withstand voltage |
5 kV (1.2/50 µs) |
| Inrush current |
30 A / 4 s |
| Insulating material group |
IIIa |
| Max. switching frequency at rated load 0.1 Hz |
Max. switching voltage, AC |
| Mechanical service life |
AC coil 5 x 106 switching |
| Mechanical switch position indicator |
No |
| Min. switching power |
1 mA @ 24 V, 10 mA @ 12 |
| Net weight |
16.4g |
| Operating Temperature |
Humidity |
| Pitch in mm (P) |
5.00mm |
| Pollution severity |
2 |
| Power Rating |
456 mW |
| Protective circuit |
Free-wheeling diode |
| Rated control voltage |
48 V DC |
| Rated current DC |
9.5mA |
| Rated switching voltage |
240 V AC |
| Rated voltage |
250 V |
| REACH SVHC |
Lead 7439-92-1 |
| ROHS |
Yes |
| RoHS Compliance Status |
Compliant with exemption |
| RoHS Version |
2011/65/EU |
| SCIP |
85ecb834-8971-4667-a012-c65a77e9d726 |
| Status indicator |
Green LED |
| Storage temperature |
-40 °C...85°C |
| Surge voltage category |
III |
| Switch-off delay |
= 6 ms |
| Test button available |
No |
| Type |
Relay |
| UL 94 flammability rating |
V-2 |
| Version |
RIDERSERIES RCI, Relay, Number of contacts: 1, |
| View of Pins from below |
DC load limit curve Resistive load |
| Width |
13mm |
| Width (inches) |
0.5118 inch |
| Wire connection method |
Plug-in connection |
| Wiring diagram |
Graph |
