Weidműller 2667850000 PCB Terminal 7.50mm Female Unshrouded

Weidmüllers 2667850000 PCB terminal is a 7.50mm female unshrouded connector. Its design facilitates easy integration into printed circuit boards for reliable electrical connections. Common applications include industrial control systems and automation equipment.

Mounting Type	Through Hole
(Tu=20°C)	(Tu=40°C)
(Tu=40°C)	pollution degree II/2
0470	57 106
60947-7-4	(Tu=20°C)
Angle PCB/conductor connection	0°/180° (horizontal)
Certificate No. (CSA)	200039-1815154
Certificate No. (cURus)	E60693
Clamping range, max.	2.5mm²
Clamping range, min.	0.12mm²
class/ pollution degree II/2	class/ pollution degree III/2
Coating	4-6 µm SN
Colour	orange
Colour chart (similar)	RAL 2000
Colour of operational elements	black
Comparative Tracking Index (CTI)	= 600
Conductor outlet direction	90°
Conductor type	Type of conductor
Connectable conductor cross section fine-strand with cable end sleeve	0.25 - 2.5
Connectable conductor cross section fine-strand without cable end sleeve	0.25 - 2.5
Connectable conductor cross section solid-core	0.5 - 2.5
Connection type conductor	Push-in clamp connection
Connection type PCB	Soldering connection
Contact Material	Cu-alloy
Contact surface	tinned
Degree of protection (IP), mounted	IP20
Depth	19.2mm
Depth (inches)	0.7559 inch
Derating curve	Derating curve
ECLASS 14.0	27-46-01-01
ECLASS 15.0	27-46-01-01
ETIM 10.0	EC002643
ETIM 8.0	EC002643
ETIM 9.0	EC002643
Flexible, max. H05(07) V-K	2.5mm²
Flexible, min. H05(07) V-K	0.25mm²
GTIN (EAN)	4050118804409
GTIN (EAN) 4008190000059	1
Height	18.3
Height (inches)	0.7205 inch
Height of lowest version	14.8mm
Housing Colour	Orange
Inflammability class of insulation material according to UL94	V0
Institute (CSA)	CSA
Institute (cURus)	CURUS
Insulating material	Wemid (PA)
IPC conformity	Conformity: The products are developed, manufactured and delivered according international
L1 in mm	37.50mm
Length pin	3.5
Material connection surface	Tin
Material insulation body	Polyamide (PA)
min.	max.
Modular spacing connections	7.5
Mounting onto the PCB	THT solder connection
Net weight	10.59g
Notes	•Additional variants on request
Number of electrical connections	6
Number of Poles	6
Number of Rows	1
Operating Temperature	-50 - 120
Operating temperature, max.	120°C
Operating temperature, min.	-50°C
Overvoltage category	II
Packaging	Box
Pin series quantity	1
Pitch in inches (P)	0.295 "
Pitch in mm (P)	7.50mm
Pollution degree	2
pollution degree III/2	pollution degree III/3
Product benefits	Product benefits
Product data	IEC: 1000 V / 24 A / 0.5 - 2.5mm²
Product family	OMNIMATE Signal - series
Product image	Dimensional drawing
Protection degree	IP20
Pull-out test	Standard
Rated current (Use group B / CSA)	20 A
Rated current (Use group B / UL 1059) 20 A	Rated current (Use group D / UL 1059) 10 A
Rated current (Use group D / CSA)	10 A
Rated current In	24
Rated current, max. number of poles	24 A
Rated current, min. number of poles	24 A
Rated Surge Voltage	6
Rated voltage	600
Rated voltage (Use group B / CSA)	300 V
Rated voltage (Use group B / UL 1059) 300 V	Rated voltage (Use group D / UL 1059) 300 V
Rated voltage (Use group D / CSA)	300 V
REACH SVHC	No SVHC above 0.1 wt%
Reference text	Length of ferrules is to
Reference to approval values	Specifications are
ROHS	Conform
RoHS Compliance Status	Compliant without exemption
Screwdriver blade	0.6 x 3.5
Screwdriver blade standard	DIN 5264
Solder eyelet hole diameter (D)	1.1mm
Solder eyelet hole diameter tolerance (D)+ 0,1 mm	Number of solder pins per pole
Solder pin dimensions	d = 0.8mm
Solder pin length (l)	3.5mm
Solid, max. H05(07) V-U	2.5mm²
Solid, min. H05(07) V-U	0.5mm²
Storage temperature, max.	70°C
Storage temperature, min.	-40°C
Stripping length	10mm
Temperature range, installation, max.	120°C
Temperature range, installation, min.	-25°C
Test	mark of origin, type identification, approval
Test for damage to and accidental	Standard
Test: Clampable cross section	Conductor type
Test: Durability of markings	Standard
tested acc. to standard	IEC 60664-1, IEC
Tinning type	matt
Type	PCB terminal
Type of banding	Other
Type of fastening	Solder
Type of PCB fastening	Other
UL 94 flammability rating	V-0
UL File Number Search	UL Website
Version	Printed circuit board terminals, 7.50 mm, Num-
VPE height	34.00mm
VPE length	351.00mm
VPE width	148.00mm
w. plastic collar ferrule, DIN 46228 pt 4,0.25 mm²	w. plastic collar ferrule, DIN 46228 pt 4,2.5mm²
Width	45.2mm
Width (inches)	1.7795 inch
Wire connection method	PUSH IN with push button
Wire cross-section, AWG, max.	AWG 12
Wire cross-section, AWG, min.	AWG 24
