Weidmuller 1697950000 Cable Ties 19x19mm Dia8mm Max 100 pieces Black Plastic

Weidmüller's CBH 19/19 black cable mount, part number 1697950000, supports a bundle diameter range of up to 8 mm. It features 4x thread and is supplied in a pack of 100 pieces, designed for industrial applications. Typical uses include securing cable ties or adhesive cable fasteners in electrical and industrial installations.

Type	Cable Mount
Material	Polyamide 6.6
Colour	Black
Basic material	Plastic
Bundle Ø (max.)	8mm
Bundle Ø range	8 mm (max)
Color	Black
Depth	2mm
Depth (inches)	0.0787 inch
Diameter mounting hole	4.1
Diameter of fastening hole	4.1mm
ECLASS 14	23-15-25-22
ECLASS 15.0	23-15-25-22
ETIM 10	EC000449
ETIM 8.0	EC000449
ETIM 9.0	EC000449
Flammability Rating	UL94 V-2
For max. bundle diameter	3.6
For re-opening	No
GTIN (EAN)	4008190883027
Halogen	No
Height	19
Height (inches)	0.748 inch
Length	19mm
Length (inches)	0.0787 inch
Max. cable tie width	3.6mm
Min. tensile strength	80
Mount	Adhesive
Net weight	0.7g
Operating Temperature Range	-40...60°C
Operating temperature range, max.	60°C
Operating temperature range, min.	-40°C
Package/Case	100
Qty.	100 items
REACH SVHC	No SVHC above 0.1 wt%
ROHS	Conform
RoHS Compliance Status	Compliant without exemption
Suitable for cable tie width to	3.6
Tensile strength	80 N
Tensile strength (Pound-force)	18 lbf
UL 94 flammability rating	V-2
UV-resistant	Yes
Weight	0.71g
Width	19mm
Width (inches)	0.748 inch
Working temperature	-40 - 60
