Weidműller 1639600000 Connector Female Unshrouded 3.50mm

Weidmuller
Order Code:

14-5841

Brand: Weidmuller MPN: 1639600000
Qty Unit Price (Ex VAT)
40+ £5.14
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Order in multiples of 40
630 in stock, despatched in 5 working days

Weidmüller BL 3.50/15/270 SN OR BX is a PCB connector (wire connection), 160 V, 12 A, Pitch in mm: 3.50, 1.5 mm², Number of poles: 15, Clamping yoke connection, Box. Pluggable PCB connection with innovative connection technology for safe and intuitive handling.
Pitch 3.5mm
No. of Rows 1
Current Rating 12A
Colour Orange
Wire Gauge (AWG) N/A
Wire Gauge (mm²) N/A
Angle contact/conductor connection 180° (horizontal)
Coating housing Uncoated
Connectable cable type Tubular cable
Connectable conductor cross section fine-strand with cable end sleeve 0.2 - 1.5
Connectable conductor cross section fine-strand without cable end sleeve 0.2 - 1.5
Connectable conductor cross section solid-core 0.2 - 1.5
Contact Type Bus
Degree of protection (IP), mounted Other
Housing colour Orange
Housing Material Plastic
Inflammability class of insulation material according to UL94 V0
Material contact Copper
Material insulation body Polybutylene terephthalate (PBT)
Material of contact surface Tin
Modular spacing connections 3.5
Modular spacing contacts 3.5
Number of Poles 15
Operating Temperature -50 - 100
Overvoltage category III
Pollution degree 2
Rated current In 10
Rated Surge Voltage 2.5
Rated voltage 160
Type of connection Flexible PCB-connector
Type of electric connection Screw connection
With protective conductor false
