Weidmüller produces the 1449470030 cable, a 3-metre long, orange, PVC-coated cable with two 1.5mm² conductors, rated for 300 volts. Its robust design makes it suitable for various electrical installations, including industrial and commercial environments. The cables durable materials ensure reliable performance and longevity in demanding applications.
| Colour |
Orange |
| Length |
3 |
| Type |
Cable |
| Anti-kink sleeve |
None |
| Cable construction |
4x2 |
| Cable Type |
S/FTP |
| Category |
6A (IEC) |
| Colour anti-kink sleeve |
Black |
| Colour outer sheath |
Green |
| Colour sequence or wires - wire pairs |
white/blue - blue, white/ |
| Cross-section |
4*2*AWG 23/7 |
| Degree of protection (IP) |
IP67 |
| ECLASS 14 |
27-06-03-08 |
| ECLASS 15.0 |
27-06-03-08 |
| ETIM 10 |
EC002599 |
| ETIM 8.0 |
EC002599 |
| ETIM 9.0 |
EC002599 |
| Flame retardant |
According to IEC/EN 60332-3-24 |
| GTIN (EAN) |
4050118264173 |
| Halogen |
Yes |
| Halogen free according to EN IEC 60754-1 |
false |
| Halogen free according to EN IEC 60754-2 |
false |
| Halogen free according to EN IEC 60754-3 |
false |
| Installation temperature |
-40 °C...80°C |
| Insulation cross-section |
1.58mm |
| Length (inches) |
118.1102 inch |
| Material connector housing, connection 1 |
Plastic |
| Material sheath |
PVC |
| Min. bending radius, once only |
4 x cable diameter |
| Min. bending radius, repetitive |
8 x cable diameter |
| Net weight |
250.8g |
| Operating Temperature |
-40 °C...80°C |
| Pin assignment |
Other |
| Plug left |
M12, X-coded, IP67, male |
| Plug right |
free conductor end |
| Pulling force |
= 150 N |
| Qty. |
1 items |
| REACH SVHC |
Lead 7439-92-1 |
| Resistance to spread of flame |
in accordance with IEC |
| ROHS |
Conform |
| RoHS Compliance Status |
Compliant with exemption |
| SCIP |
67cf1078-beca-4687-860b-dc475a6ec24a |
| Sheath diameter, max. |
8.8mm |
| Sheathing colour |
green (RAL 6018) |
| Shielding |
S/FTP |
| Standard, assembly |
UL-Style 2461 |
| Storage temperature |
-40 °C...80°C |
| Test voltage: wire-wire-shield |
800 Veff, 50 Hz, 1 min |
| Transmission rate |
10 Gbit/s |
| Type of connector connection 1 |
M12 |
| Version |
Connecting line, M12 X-type IP 67 straight male, |
