WAGO 857-354 Relay SPDT-CO 24VAC/DC

24V AC/DC miniature switching relay that plugs into a base with the JUMPFLEX system that utilises a single, flexible in-line jumper system (e.g. for supply voltages) that eliminates discrete wiring. The relays can be replaced quickly and easily when required.

• DIN-rail mounting
• Load voltage 250V AC/DC
• SPDT-CO Circuit
• Mechanical life 5 x 10⁶ operations
• CAGE CLAMP termination

Category	Relay and Optocoupler Modules
Coil Current	6A
Coil Voltage (DC)	24V DC
Connection	Push-in CAGE CLAMP®
Contact Configuration	SPDT-CO
Fine-stranded conductor max. AWG	14 AWG
Fine-stranded conductor max. mm²	2.5mm²
Fine-stranded conductor min. AWG	14 AWG
Fine-stranded conductor min. mm²	0.34mm²
Flammability class according to UL94	V0
Height	81mm
Height inch	3.701inches
Height mm	94mm
Length	94mm
Mounting Type	Rail
Operating Temperature	-25 to +60°C
Product Main Function	Relay module
Single-stranded conductor max. AWG	14 AWG
Single-stranded conductor max. mm²	2.5mm²
Single-stranded conductor min. AWG	22 AWG
Single-stranded conductor min. mm²	0.34mm²
Stripping length of 1 mm	9mm
Stripping length up to 1 mm	10mm
Switching Current Max	6A
Switching Power	1250VA
Switching Voltage Max (AC)	250V AC
Unit Weight	KGM
Weight	30.850g
Width	6mm
Width inch	0.236inches
Width mm	6mm
