WAGO 788-384 Safety Relay 24V DC 2 Change-Overs 15x64x86mm

Image Representative of Range

WAGO 788-384 Safety Relay 24V DC 2 Change-Overs 15x64x86mm

WAGO
Order Code:

13-4424

Brand: WAGO MPN: 788-384 EAN-13: 2050000907746
Qty Unit Price (Ex VAT)
1+ £26.64
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
13 in stock, despatched in 4 working days

The WAGO safety relay 788-384 operates at 24 V DC and features two change-over contacts. With dimensions of 15 x 64 x 86 mm, it is designed for compact installation. It is ideal for applications in workplace safety, industrial plant safety, and access control systems.
Type Safety relay
Mounting Type DIN rail
Width 15mm
Height 64mm
Ambient temperature -25 - +50°C
Category Relay and Optocoupler Modules
Colour Grey
Connection Push-in CAGE CLAMP®
Contact Type 2 change-overs
Depth 86mm
Dielectric Strength (Contact/coil) 4 kV/(open contact) 1.5kV
Dim (W x H x D) 15 x 64 x 86 mm
Durability 30 x 106 Switching operations
Fine-stranded conductor max. AWG 14 AWG
Fine-stranded conductor max. mm² 2.5 mm²
Fine-stranded conductor min. AWG 14 AWG
Fine-stranded conductor min. mm² 0.34 mm²
Height inch 3.386inches
Height mm 86mm
IP Rating IP20
Misc Attribute 1 Plug base with safety relay
Nominal Current 6A
Nominal voltage (details) 24V DC
Operating Voltage 24V DC
Product Main Function Relay module
Single-stranded conductor max. AWG 14 AWG
Single-stranded conductor max. mm² 2.5 mm²
Single-stranded conductor min. AWG 22 AWG
Single-stranded conductor min. mm² 0.34 mm²
Stripping length of 1 mm 9mm
Stripping length up to 1 mm 10mm
Switching Voltage 250V AC
Unit Weight KGM
Weight 50.300 g
Width inch 0.591inches
Width mm 15mm
