WAGO 734-110/107-000 Female MCS-MINI 10P 3.5mm Screw Flange

MPN: 734-110/107-000
Brand: WAGO
EAN-13: 4045454618971
Order Code: 57-2693
Country of Origin: Germany

RoHS Compliant
Free UK shipping available

View Full Product Range (11)

Inc VAT

Qty	Unit Price (Ex VAT)
50+	£6.47

Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT

Order in multiples of 50

Available to back orderBack-order availability date - 22/05/2026

Product Range
Quick Quote

AWG size: 28 - 14
Additional product details: FEDERL.GER.3,50MM 10-P.KN SCHRAUBFL.
Colour: Light grey
Contact material: Copper alloy
Grid pitch: 3.5mm
Stripping length: 6 - 7mm
Type (manufacturer type): FEDERL.GER.3,50MM 10-P.KN SCHRAUBFL.

Body Style	Female connector/socket
Pitch	3.5mm
No of Ways Per Row	10
No. of Rows	1
Current Rating	10 A
Colour	Grey
Wire Gauge (AWG)	28 AWG
Wire Gauge (mm²)	0.08mm²
Category	PCB Terminal Blocks and Connectors;Pluggable Connectors;Lighting Connection
Connection	CAGE CLAMP®
Depth	18.6mm
Depth inch	0.732inches
Flammability class according to UL94	V0
Height	13.4mm
Height inch	0.528inches
Rated surge voltage (II / 2)	2.5 kV
Rated voltage (II / 2)	320 V
Stripping length of 1 mm	6mm
Stripping length up to 1 mm	7mm
Total number of potentials	10
Type of operation	Operating tool
Unit Weight	KGM
Weight	8.358g
Width	44.5mm
Width inch	1.752inches
