WAGO 231-315/008-000 Female Snap-in Mounting Foot 15P Pitch 5.08 mm

MPN: 231-315/008-000
Brand: WAGO
EAN-13: 4044918349031
Order Code: 57-3334
Country of Origin: Germany

RoHS Compliant
Free UK shipping available

View Full Product Range (23)

Inc VAT

Qty	Unit Price (Ex VAT)
25+	£8.05

Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT

Order in multiples of 25

Available to back orderBack-order availability date - 21/05/2026

Product Range
Quick Quote

Number of Poles: 15
AWG size: 28 - 12
Additional product details: FEM.CONN.W.COD.FG.(LATCH)FX.FT.
Colour: Orange
Contact material: Copper alloy
Grid pitch: 5.08mm
Stripping length: 8 - 9mm
Type (manufacturer type): FEM.CONN.W.COD.FG.(LATCH)FX.FT.
Pack Size: 25

Body Style	Female connector/socket
Pitch	5.08mm
No of Ways Per Row	15
No. of Rows	1
Current Rating	16 A
Colour	Orange
Wire Gauge (AWG)	28 AWG
Wire Gauge (mm²)	0.08mm²
Category	PCB Terminal Blocks and Connectors;Pluggable Connectors;Lighting Connection
Connection	CAGE CLAMP®
Depth	26.45mm
Depth inch	1.041inches
Flammability class according to UL94	V0
Height	18.8mm
Height inch	0.74inches
Rated surge voltage (II / 2)	4 kV
Rated voltage (II / 2)	630 V
Stripping length of 1 mm	8mm
Stripping length up to 1 mm	9mm
Total number of potentials	15
Type of operation	Operating tool
Unit Weight	KGM
Weight	27.490g
Width	77.7mm
Width inch	3.059inches
