WAGO 231-122/027-000 Female Through Fixing Flanges 22P Pitch 5mm0

WAGO
Order Code:

57-3043

Brand: WAGO MPN: 231-122/027-000 EAN-13: 4044918343060
Qty Unit Price (Ex VAT)
10+ £12.90
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Order in multiples of 10
Available to back orderBack-order availability date - 23/04/2026


  • Number of Poles: 22
  • AWG size: 28 - 12
  • Additional product details: FEMALE CONN. 22P FIX.FLANGE 5MM
  • Colour: Grey
  • Contact material: Copper alloy
  • Grid pitch: 5mm
  • Stripping length: 8 - 9mm
  • Type (manufacturer type): FEMALE CONN. 22P FIX.FLANGE 5MM
  • Pack Size: 10
Body Style Female connector/socket
Pitch 5mm
No of Ways Per Row 22
No. of Rows 1
Current Rating 16 A
Colour Grey
Wire Gauge (AWG) 28 AWG
Wire Gauge (mm²) 0.08 mm²
Category PCB Terminal Blocks and Connectors;Pluggable Connectors;Panel Feedthrough Components
Connection CAGE CLAMP®
Depth inch 1.041 inches
Depth mm 26.45mm
Height inch 0.563 inches
Height mm 14.3mm
Rated surge voltage (II / 2) 4 kV
Rated voltage (II / 2) 630 V
Stripping length of 1 mm 8mm
Stripping length up to 1 mm 9mm
Total number of potentials 22
Type of operation Operating tool
Unit Weight KGM
Weight 39.787 g
Width inch 4.913 inches
Width mm 124.8mm
