Wachendorff UR32742A PID Controller Universal Input 5A Relay IP65

The Wachendorff UR32742A Temperature Controller is a PID controller compatible with sensors like Pt100, Pt500, and Pt1000, tailored for precise temperature regulation. It is equipped with a 5 A relay for reliable switching and measures 53 x 77 x 35 mm, making it compact for installation. Ideal for industrial temperature management applications, it provides high accuracy and versatility.

Type	Temperature controller
Assembly dimensions	32 x 74mm
Digital inputs	1 x digitally programmable
Dim (L x W x H)	53 x 77 x 35mm
Height	35mm
Interfaces	RS485 Modbus RTUm
IP Rating	IP65 (on front)/IP20 (on back)
Length	53mm
Mounting	Recess-mount
Sensor Type	Thermocouple type K, S, R, J, Pt100, PT500, Pt1000, Ni100, PTC1K, NTC10K
Thermostat type	PID
Weight	112g
Width	77mm
