Vogt3921 Bullet Connector 1.5-2.5mm² 5mm Pin Partially Insulated Blue

Image Representative of Range

Vogt3921 Bullet Connector 1.5-2.5mm² 5mm Pin Partially Insulated Blue

Vogt Verbindungstechnik
Standard range
Order Code:

13-3993

Brand: Vogt Verbindungstechnik MPN: 3921 EAN-13: 2050000243936
Qty Unit Price (Ex VAT)
20+ £0.336
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
Order in multiples of 1
749 in stock, despatched in 4 working days

Vogt Verbindungstechnik produces the 3921 bullet connector designed for wire sizes ranging from 1.50 mm² to 2.50 mm² with a pin diameter of 5 mm. The connector is partially insulated and coloured blue, suitable for reliable electrical connections. It is typically used in automotive and electronic applications requiring secure crimp connectors.
Type Bullet connector
AWG (min.) 16
AWG max. 14
Contact material Brass tin plated
Cross section 1.5 - 2.5mm²
Cross-section range 1.50 - 2.50 mm²
Factory colour Blue
Insulation PVC
Insulation material PVC
Insulation type Partially insulated
Material (details) Brass, tin-plated
max. cross section 2.50mm²
Min. cross section 1.50mm²
Pin Ø 5mm
RoHS-compliant Yes
Support sleeve Yes
Temperature range -10 - +75°C
