Vishay DCu0805 Cermet Resistor 680Ω SMD 0805 0.125W 1% 100PPM Tape Cut

Vishay DCu0805 Cermet Resistor, part number 427845, is a precision surface-mount device designed for electronic circuit applications requiring reliability and accuracy. This resistor features a resistance value of 680 ohms with a power rating of 0.125 watts in the 0805 package size, offering a tolerance of 1% and a temperature coefficient of 100 ppm/°C. The cermet composition ensures stability under varying temperature and humidity conditions, making it suitable for use in high-frequency and precision circuits such as medical diagnostic equipment, telecommunications, and instrumentation. This resistor type is delivered in a tape-cut format for ease of use in automated pick-and-place assembly processes. The adherence to industry-standard parameters makes it an integral component in designing dependable electronic systems.

To find out more about our range of Vishay resistors, diodes, capacitors and switches, please visit our Vishay brand page.

Type	DCU 0805
Resistance	680Ω
Power Rating	0.125W
Content	1
Design Type	Thick film
Dimensions	(L x W x H) 2 x 1.2 x 1.2 mm
Height	1.2mm
Length	2mm
Product Type	Cermet resistor
Temperature Coefficient	100ppm
Tolerance ±	1%
Width	1.2mm
