TruComponents 782691 Pushbutton ,Panel Mount,Off/(On),NO/NC,Solder,IP40

TruComponents
Order Code:

78-2691

Brand: TruComponents MPN: 782691 EAN-13: 4064161171012
Qty Unit Price (Ex VAT)
2+ £2.82
5+ £2.76
10+ £2.69
25+ £2.63
50+ £2.57
100+ £2.52
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Order in multiples of 1
114 in stock, despatched in 4 working days

The TruComponents TC-9428044 is a panel mount pushbutton switch with an Off/(On) momentary action, featuring NO/NC contacts. It has a voltage rating of 250 V and a current rating of 3 A, suitable for various applications requiring brief activation, such as in control panels or laboratory equipment. This non-illuminated pushbutton offers IP40 protection and is designed for soldering connections.
Type Pushbutton
Board thickness (max.) 8mm
Button diameter 12mm
Casing/button colour Blue
Contact Material Silver alloy
Durability 200000
Electrical lifespan 50000
Functions momentary
IP Rating IP40
Lighting type None
Max. temperature +55°C
Min. temperature -25°C
Misc Attribute LAS2Y-11/B
Recess depth 28mm
Recess diameter 12mm
Switch position 1 x Off/(On)
Switching current (max.) 3A
Switching Voltage 250V
