TruComponents 751505 Toggle switch Panel Mount (On)/Off/(On) SPDT Solder Term

TruComponents
Order Code:

75-1505

Brand: TruComponents MPN: 751505 EAN-13: 4064161162058
Qty Unit Price (Ex VAT)
1+ £4.39
5+ £3.90
10+ £3.58
25+ £3.38
50+ £3.19
100+ £3.08
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
1,641 in stock, despatched in 4 working days

The TruComponents 751505 Toggle Switch is a high-quality, reliable component designed for a wide range of applications. This Single Pole Double Throw (SPDT) switch offers an On/On functionality, making it ideal for controlling two different circuits with a single switch. The chrome-plated toggle has a removable red insulating sleeve.
Contact Configuration 1 x (On)/Off/(On)
Switch Function momentary/0/momentary
Current Rating (Amps) 3A
Casing/button colour Red
CS 4.7mm
Dim (L x W x H) 13 x 7.9 x 32.85 mm
Height 32.85mm
Industrial packaging Compatible with
Length 13mm
Lighting type None
Max. temperature 80°C
Min. temperature -10°C
Misc Attribute TC-9353992
Number of Pins 3
Recess depth 13.46mm
Recess diameter 6.35mm
Switching Voltage 250V AC
Termination Style Solder tag
Type Toggle switch
Width 7.9mm
