TruComponents 656418 Stranded 3x0.75mm² Wh 20m

These cables are intended for the connection of light electrical devices (radios, table lamps, clocks, etc.) with low mechanical demands in the home, kitchen and office. CCA describes bi-metallic single and multi-wired lines/cables that are copper-plated with an aluminium core for high-frequency usage areas. Specification explanation: The "skin-effect", also known as current displacement, is a physical phenomenon caused by high-frequency alternating currents. The current density inside the conductor reduces compared to that at the outer surface as the frequency increases.

Insulation material	PVC
Core layout	27 x 0.19mm
Cross section	3 x 0.75 mm²
Cross section (each core)	0.75mm²
Factory colour	White
Halogen-free	No
Height	100mm
Hole Ø (coil)	35mm
Manufacturer part #	1566989
Material (details)	PVC
Max. temperature range (fixed installation)	+70°C
Min. temperature range (fixed installation)	-20°C
Misc Attribute	NYFAZ/CCA
No. of leads	3
Nominal voltage	48V
Packaged	Yes
Sold per metre	No
Type	Cable
Width	100mm
