TRU COMPONENTS TC-12835296 is a push-button switch designed for reliable manual actuation in various industrial and automation applications. This momentary switch, featuring a red actuator with a diameter of 25 mm, operates with a voltage of 24 V and supports a current rating of up to 0.5 A. With an ingress protection rating of IP65, this switch is suitable for use in harsh environments where dust and water ingress could be a concern. The design integrates seamlessly with equipment using the TC-TS22A10YSSR12M12 male connector, allowing for straightforward connectivity and installation. Common uses for this switch include control panels, machinery interfaces, and situations where transient operation of a circuit is required, such as emergency stops or operator input devices.
| Type |
PNP output, LED operating voltage 12 V |
| Switch Function |
1 breaker |
| Mounting |
Panel |
| Panel Cutout Dimensions |
25 dia |
| Actuating Force |
0N |
| Board thickness (max.) |
8mm |
| Bulb Type |
LED (monochrome) |
| Button Diameter |
13.7mm |
| Casing/button colour |
Stainless steel |
| Colour |
Red |
| Connection |
M12 plug |
| Contact Resistance |
20mO |
| Content |
1 |
| Diameter |
25mm |
| Dimensions |
(Ø) 25mm |
| Electrical lifespan |
50,000,000 cycles |
| Front panel cut-out |
22mm |
| Functions |
momentary |
| Insulation Resistance |
600VDC 10mO |
| IP Rating |
IP65 |
| Lighting Type |
Circular lighting |
| Material |
Stainless steel |
| Maximum Temperature |
55°C |
| Min. temperature |
-25°C |
| Product Type |
Touch button |
| Recess Diameter |
22mm |
| Switch position |
1 x Off/(On) |
| Switch/button features |
capacitive |
| Switching current (inductive) |
0.5A |
| Switching current (max.) |
0.5A |
| Switching Voltage |
24V |
