TRU COMPONENTS 1581895 Zener diode DO 35 6.8 V 510 mW reliable power control

TRU COMPONENTS 1581895 is a Zener diode encapsulated in a DO-35 housing, offering a Zener voltage of 6.8 V and a maximum power dissipation of 510 mW. Designed for reliable voltage regulation and power control, this diode employs a p-n junction to establish a stable Zener voltage, making it ideal for use in voltage reference circuits, surge suppression, and signal clipping applications. Its robust design is well-suited for continuous use in demanding environments, providing consistent performance in electronic circuits requiring precise voltage control. Often utilised in power management systems, these Zener diodes are a critical component in ensuring circuit stability and protection against voltage fluctuations.

Type	TC-ZPD6.8
Configuration	1 diode
Enclosure	DO 35
Impedance	4.5Ω
Impedance reference	5mA
Mounting Type	Through-hole mounting
Operating temperature (max.)	+175°C
Operating temperature (min.)	-50°C
Power (max) P(TOT)	510mW
Product Type	Zener diode
Residual reverse leakage current	78mA
U<sub>z</sub> (max.)	7.2V
U<sub>z</sub>(min.)	6.4V
Z Voltage U(Z)	6.8V
