TracoPower TXH 060-124 SMPSU 25.2V DC 2.5A 60W 1 pc Highly Reliable

TracoPower
Extended range
Order Code:

07-8424

Brand: TracoPower MPN: TXH 060-124
Qty Unit Price (Ex VAT)
1+ £44.25
5+ £42.92
10+ £41.59
25+ £39.83
50+ £38.06
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 13/07/2025

The TracoPower TXH 060-124 is a 60 W printed circuit board power supply unit delivering 25.2 V DC at 2.5 A. It is a PCB mount SMPSU with solder lugs designed for easy integration into electronic systems. This reliable power supply is suitable for various industrial and commercial applications.
Type SMPSU
Connection Screw terminal
Dim (L x W x H) 80.0 x 50.6 x 38.0 mm
Height 38.0mm
Input voltage (max.) 264V AC
Length 80.0mm
Max. operating temperature (derating) 70°C
Max. output current 2.5A
Max. temperature 70°C
Min. input voltage 90V AC
Min. temperature -30°C
Misc Attribute 2 closed
No. of outputs 1
Operating temperature (max.) 70°C
Operating temperature (min.) -30°C
Output current (max.) - rounded 2.5A
Output current (min.) 0mA
Output voltage (max.) 25.2V DC
Output voltage (min.) 22.8V DC
Power 60W
Weight 220g
Width 50.6mm
