TracoPower TSR 0.6-4850WI DC/DC converter 600mA 7W 1 output

TracoPower TSR 0.6-4850WI is a high-performance DC-DC converter designed for efficient power regulation in electronic circuits. This converter provides a maximum output current of 600 mA and delivers up to 7 W of power through a single output, making it suitable for a wide range of low to mid-power applications. The TSR 0.6-4850WI is particularly well-suited for printed circuit board (PCB) integration due to its compact design, enabling seamless implementation in portable electronics, telecommunications equipment, and industrial control systems. With its robust construction and reliable performance, this converter is ideal for applications requiring precise DC voltage regulation and efficient current rectification. This component is typically utilised in scenarios where stable power supply is crucial, such as embedded systems and point-of-load converters.

Connection	Solder pins
Content	1
Dimensions	(L x W x H) 12.0 x 8.6 x 13.4 mm
Efficiency (max.)	89%
Height	13.4mm
Input voltage (max.)	72V DC
Length	12.0mm
Max. output current	600mA
Min. input voltage	9V DC
No. of outputs	1
Operating temperature (max.)	85°C
Operating temperature (min.)	-40°C
Output current (max.) - rounded	600mA
Output voltage (max.)	5.0V DC
Output voltage (min.)	5.0V DC
Power	7W
Product Type	DC/DC converter (print)
PSU features	DC-to-DC converter
Type	TSR 0.6-4850WI
Weight	3g
Width	8.6mm
