TracoPower TSR 0.6-4833WI DC/DC converter 600mA 5W 1 output

TracoPower TSR 0.6-4833WI is a high-efficiency DC-DC converter designed for applications requiring stable and reliable voltage conversion. This direct current converter supports an output of 600 mA and delivers up to 5 W of power with a single output configuration. As a print converter, it is particularly suited for circuit board integration where space and energy efficiency are crucial. The TSR 0.6-4833WI is ideal for use in industrial automation, communications equipment, and embedded systems, where precision voltage regulation and compact design are paramount. With its robust performance, the converter ensures optimal functionality in environments demanding consistent power delivery.

Connection	Solder pins
Content	1
Dimensions	(L x W x H) 12.0 x 8.6 x 13.4 mm
Efficiency (max.)	85%
Height	13.4mm
Input voltage (max.)	72V DC
Length	12.0mm
Max. output current	600mA
Min. input voltage	9V DC
No. of outputs	1
Operating temperature (max.)	85°C
Operating temperature (min.)	-40°C
Output current (max.) - rounded	600mA
Output voltage (max.)	3.3V DC
Output voltage (min.)	3.3V DC
Power	5W
Product Type	DC/DC converter (print)
PSU features	DC-to-DC converter
Type	TSR 0.6-4833WI
Weight	3g
Width	8.6mm
