TracoPower TSR 0.5-24120 DC/DC Converter 24V to 12V 500mA SIL-Housing

TracoPower
Order Code:

07-8399

Brand: TracoPower MPN: TSR 0.5-24120
Qty Unit Price (Ex VAT)
1+ £4.06
5+ £3.94
10+ £3.82
25+ £3.66
50+ £3.49
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 25/01/2026

The TracoPower TSR 0.5-24120 is a DC/DC converter that transforms 24 V DC input to a 12 V DC output at 500 mA. It features a compact design, suitable for various print converter applications. This converter is ideal for use in electronic equipment where efficient voltage conversion is required.
Connection Solder pins
Dim (L x W x H) 11.5 x 14.3 x 7.55 mm
Efficiency (max.) 97%
Enclosure SIL
Height 7.55mm
Input voltage (max.) 36V DC
Length 11.5mm
Max. output current 500mA
Min. input voltage 18V DC
Misc Attribute 1 TSR 0.5-2 4120
Nominal Voltage 24V DC
Number of Outputs 1
Operating temperature (max.) 90°C
Operating temperature (min.) -40°C
Output current (max.) - rounded 500mA
Output voltage (max.) 12V DC
Output voltage (min.) 12V DC
Output voltages 12V DC
Type DC/DC converter (print)
Width 14.3mm
