TracoPower TPP 15-124A-D SMPSU 24V DC 625mA 15W Compact Power Supply

TracoPower
Standard range
Order Code:

07-8336

Brand: TracoPower MPN: TPP 15-124A-D
Qty Was Unit Price (Ex VAT)
1+ £25.97   £25.32
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
Available to back order

The TracoPower TPP 15-124A-D is a printed circuit board power supply unit providing 24 V DC at 625 mA. This 15 W PSU features solder lugs for PCB mounting, making it suitable for quick and efficient circuit board equipping. It's typically used in applications requiring a reliable and compact switched-mode power supply unit.
Type SMPSU
Connection Solder pins
Dim (L x W x H) 38.1 x 25.4 x 25.8 mm
Height 25.8mm
Input voltage (max.) 264V AC
Length 38.1mm
Max. output current 625mA
Max. temperature 85°C
Min. input voltage 85V AC
Min. temperature -40°C
Misc Attribute 1 TPP 15-124A-D
Misc Attribute 2 open
No. of outputs 1
Output current (max.) - rounded 625mA
Output current (min.) 0mA
Output voltage (max.) 24V DC
Output voltage (min.) 24V DC
Power 15W
Weight 16.5g
Width 25.4mm
