TracoPower TPP 15-103-D SMPSU 3.3V DC 4A 13.2W High-Efficiency Module

TracoPower
Order Code:

07-8325

Brand: TracoPower MPN: TPP 15-103-D
Qty Unit Price (Ex VAT)
1+ £36.13
5+ £35.04
10+ £33.96
25+ £32.52
50+ £31.07
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 29/12/2025

The TracoPower TPP 15-103-D is a PCB mount power supply unit providing a 3.3 V DC output at 4 A with a total power of 13.2 W. This SMPSU is designed with solder lugs for easy installation and is suitable for equipping printed circuit boards. It is ideal for applications requiring robust and compact power solutions.
Connection Solder pins
Dim (L x W x H) 42.0 x 28.9 x 25.3 mm
Height 25.3mm
Input voltage (max.) 264V AC
Length 42.0mm
Max. operating temperature (derating) 70°C
Max. output current 4A
Max. temperature 85°C
Min. input voltage 85V AC
Min. temperature -40°C
Misc Attribute 2 closed
Number of Outputs 1
Operating temperature (max.) 85°C
Operating temperature (min.) -40°C
Output current (max.) - rounded 4A
Output current (min.) 0mA
Output voltage (max.) 3.3V DC
Output voltage (min.) 3.3V DC
Power 13.2W
Type SMPSU
Width 28.9mm
