TracoPower TOP 60522 PSU 5V DC 6A 55W Reliable Power Source

TracoPower
Standard range
Order Code:

07-8315

Brand: TracoPower MPN: TOP 60522
Qty Unit Price (Ex VAT)
1+ £41.53
5+ £40.29
10+ £39.03
25+ £37.38
50+ £35.71
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
2 in stock, despatched in 4 working days

TracoPower's TOP 60522 power supply unit is a PCB-mounted component delivering 5 V DC and up to 6 A, with a power output of 55 W. It is equipped with solder lugs for secure attachment and integration into printed circuit boards. This PSU is typically used in applications requiring reliable power management on circuit boards.
Type PSU
Connection Connector
Dim (L x W x H) 30.0 x 50.8 x 101.6 mm
Height 101.6mm
Input voltage (max.) 264V AC
Length 30.0mm
Max. output current 6A
Max. temperature 70°C
Min. input voltage 90V AC
Min. temperature -10°C
Misc Attribute 1 TOP 60522
Misc Attribute 2 open
No. of inputs 1
No. of outputs 3
Output current (max.) - rounded 6A
Output current (min.) 0A
Output current 2 (max.) 3A
Output current 2 (min.) 0A
Output current 3 (max.) 0.5A
Output current 3 (min.) 0A
Output voltage (max.) 5V DC
Output voltage (min.) 5V DC
Output voltage 2 (max.) 12V DC
Output voltage 2 (min.) 12V DC
Output voltage 3 (max.) -12V DC
Output voltage 3 (min.) -12V DC
Power 55W
Weight 205g
Width 50.8mm
