TracoPower TOP 60254 PSU 5V DC 6A 55W Reliable Power Supply Unit

TracoPower
Order Code:

07-8314

Brand: TracoPower MPN: TOP 60254
Qty Unit Price (Ex VAT)
1+ £74.16
5+ £71.94
10+ £69.72
25+ £66.75
50+ £63.78
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 28/12/2025

TracoPower is the manufacturer of the TOP 60254, a printed circuit board power supply unit with a 5 V DC output and a current of 6 A, delivering a power of 55 W. This PCB mount PSU with solder lugs is designed for easy installation on circuit boards. Typical applications include powering electronic devices and components that require stable DC power.
Connection Connector
Dim (L x W x H) 30.0 x 50.8 x 101.6 mm
Height 101.6mm
Input voltage (max.) 264V AC
Length 30.0mm
Max. output current 6A
Max. temperature 70°C
Min. input voltage 90V AC
Min. temperature -10°C
Misc Attribute 2 open
Number of Inputs 1
Number of Outputs 2
Output current (max.) - rounded 6A
Output current (min.) 0A
Output current 2 (max.) 1.5A
Output current 2 (min.) 0A
Output voltage (max.) 5V DC
Output voltage (min.) 5V DC
Output voltage 2 (max.) 24V DC
Output voltage 2 (min.) 24V DC
Power 55W
Type PSU
Width 50.8mm
