TracoPower TMR 3-4811WIR DC/DC Converter 48V DC 600mA 3W SIL-8 Housing

TracoPower
Order Code:

07-8298

Brand: TracoPower MPN: TMR 3-4811WIR
Qty Unit Price (Ex VAT)
1+ £22.04
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 13/01/2026

The TracoPower TMR 3-4811WIR is a DC/DC converter capable of converting 48 V DC at 600 mA with a power output of 3 W, featuring one output. This print converter is designed to provide reliable power conversion in industrial and transportation applications. Its compact design and high efficiency make it ideal for use in harsh environments where space and durability are critical.
Output Voltage 5.0V DC
Input Voltage Range 75V DC
Output Current 600mA
Number of Outputs 1
Connection Solder pins
Dim (L x W x H) 9.6 x 21.8 x 15.3 mm
Efficiency (max.) 81%
Enclosure SIL 8
Height 15.3mm
Insulation Voltage 3000V DC
Length 9.6mm
Max. output current 600mA
Min. input voltage 18V DC
Nominal Voltage 48V DC
Operating temperature (max.) +90°C
Operating temperature (min.) -40°C
Power 3W
Type DC/DC converter (print)
Width 21.8mm
