TracoPower TMPS 03-115 SMPSU 15VDC 0.2A 3W Compact AC/DC Fully Encapsulated

TracoPower
Standard range
Order Code:

07-8265

Brand: TracoPower MPN: TMPS 03-115
Qty Unit Price (Ex VAT)
1+ £14.40
5+ £13.92
10+ £13.49
25+ £12.91
50+ £12.35
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
3 in stock, despatched in 4 working days

TracoPower manufactures the TMPS 03-115 SMPSU, a compact 15 V DC power supply unit with a 0.2 A current rating and 3 W power capacity. This PCB mount power supply is designed with solder lugs suitable for surface mounting on printed circuit boards. It is ideal for applications requiring efficient and reliable power delivery in compact electronic devices and systems.
Type SMPSU
Connection Solder pins
Dim (L x W x H) 16.3 x 25.4 x 25.4 mm
Height 25.4mm
Input voltage (max.) 264V AC
Length 16.3mm
Max. operating temperature (derating) 60°C
Max. output current 0.2A
Min. input voltage 85V AC
Min. operating temperature (derating) -25°C
Misc Attribute 1 TMPS 03-115
Misc Attribute 2 closed
No. of outputs 1
Operating temperature (max.) 70°C
Output current (max.) - rounded 200mA
Output current (min.) 0mA
Output voltage (max.) 15V DC
Power 3W
Weight 17.4g
Width 25.4mm
