TracoPower TMDC 40-2418 DC/DC Converter 24V to 48V 835mA 40W Screw Terminals

TracoPower
Order Code:

07-8254

Brand: TracoPower MPN: TMDC 40-2418
Qty Unit Price (Ex VAT)
1+ £58.40
5+ £56.64
10+ £54.90
25+ £52.56
50+ £50.23
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 28/12/2025

The TracoPower TMDC 40-2418 is a DC/DC converter module designed to convert 24 V DC to 48 V DC with an output current of 835 mA and a power capacity of 40 W. This compact converter is typically used in industrial and telecommunications applications requiring efficient power management. With a single output, it offers reliable performance for a range of electronic systems.
Connection Screw terminal
Dim (L x W x H) 63.8 x 112 x 25.6 mm
Efficiency (max.) 89%
Height 25.6mm
Input voltage (max.) 36V DC
Insulation Voltage 2500V DC
Length 63.8mm
Max. output current 835mA
Min. input voltage 9V DC
Misc Attribute 2 40-2418 TMDC
Nominal Voltage 24V DC
Number of Outputs 1
Operating temperature (max.) 85°C
Operating temperature (min.) -40°C
Output current (max.) - rounded 835mA
Output voltage (max.) 48V DC
Output voltage (min.) 48V DC
Output voltages 48V DC
Power 40W
Type DC/DC converter (module)
Width 112mm
