TracoPower THL 6-2411WISM DC/DC Converter 24V-5.1V 6W 1 Output SMD

TracoPower
Order Code:

07-8211

Brand: TracoPower MPN: THL 6-2411WISM
Qty Unit Price (Ex VAT)
1+ £28.09
5+ £27.24
10+ £26.40
25+ £25.28
50+ £24.15
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 25/01/2026

This TracoPower THL 6-2411WISM is a surface-mount DC/DC converter with an input of 24 V DC and an output of 5.1 V DC at 1.2 A, delivering 6 W of power. It features a single output and is ideal for applications requiring efficient voltage conversion in compact spaces. Typical uses include industrial electronics and telecommunications systems.
Connection SMD
Dim (L x W x H) 25.4 x 22 x 10.05 mm
Efficiency (max.) 79%
Enclosure SMD
Height 10.05mm
Input voltage (max.) 36V DC
Insulation Voltage 1500V DC
Length 25.4mm
Max. output current 1.2A
Min. input voltage 9V DC
Misc Attribute 1 6-2411 THL WISM
Nominal Voltage 24V DC
Number of Outputs 1
Operating temperature (max.) 75°C
Operating temperature (min.) -40°C
Output current (max.) - rounded 1.2A
Output voltage (max.) 5.1V DC
Output voltage (min.) 5.1V DC
Output voltages 5.1V DC
Power 6W
Type DC/DC converter (SMD)
Width 22mm
