TracoPower TEL 10-1223 DC/DC converter 333mA 10W 2 outputs

TracoPower TEL 10-1223 is a robust DC-DC converter designed with high precision to deliver reliable power conversion in demanding applications. This device features dual output, supplying up to 333 mA with a total power capacity of 10 watts. It operates efficiently across a wide range of input voltages, providing stable direct current output suitable for sensitive electronic components. The TEL 10-1223 is typically used in telecommunications, industrial electronics, and distributed power architectures, where compact size and high performance are crucial. Engineered for print circuit board integration, it offers efficient power rectification while maintaining thermal stability and electrical isolation between the inputs and outputs.

Power Rating	10W
Connection	Solder pins
Content	1
Dimensions	(L x W x H) 23.80 x 13.70 x 8 mm
Efficiency (max.)	86%
Height	8mm
Input voltage (max.)	18V DC
Insulation Voltage	1500V DC
Length	23.80mm
Max. output current	333mA
Min. input voltage	9V DC
No. of outputs	2
Operating temperature (max.)	88°C
Operating temperature (min.)	-40°C
Output current (max.) - rounded	333mA
Power	10W
Product Type	DC/DC converter (print)
Type	TEL 10
Weight	6.50g
Width	13.70mm
